LMV 311 High Speed Centrifugal Pump

  • 1
  • 2

Brand Name : Sunstrand

Model Number : LMV-311

Certification : IOS9001/IOS9002/CUTR

Place of Origin : China

MOQ : 1

Price : Negotiation

Payment Terms : T/T

Supply Ability : 10set/month

Delivery Time : 60 days

Packaging Details : Wooden Case

Product Name : LMV 311 High Speed Centrifugal Pump

Max Head : 1920 m

Feature : LMV 311 API 610 Pump

Max Suction Pressure : 6.8MPa

Motor Power : Power 132kW

Operating Temperature : -130~+340°C

Contact Now

LMV 311 High Speed Centrifugal Pump
Product Overview

The LMV311 High-Speed Vertical Centrifugal Pump represents the ultimate solution for high-speed liquid transfer demands in the global petrochemical and chemical industries.

As an experienced supplier in high-speed rotating equipment, Sunstrand provides a high-performance alternative to the LMV 311 that offers 100% dimensional interchangeability while incorporating localized improvements in durability and maintenance convenience.

Field Experience & Reliability
  • High-pressure ammonia reflux - Optimized seal chamber thermal balance design addresses original model's tendency for seal face freezing
  • Proven reliability - Replacement solution has operated for more than 8,000 hours without maintenance in multiple million-ton-per-year refining projects
Precision Engineering
High-Speed Gearbox

AGMA Class 12 precision with 17CrNiMo6 case-carburized and hardened steel construction

Dynamic Balancing

Rotor assemblies meet ISO 1940 G1.0 standards, ensuring quiet operation even at 15,000 RPM

NPSH Optimization

CFD-simulated inducer design reduces NPSHr to below 2.0 meters, eliminating cavitation problems

Key Features
100% Physical & Hydraulic Interchangeability

Strictly follows API 610 (OH6) standards. Install directly on existing piping without modifications to flange positions, foundation, or motor wiring.

Precision High-Speed Gearing

High-strength alloy steel forged gears precision ground to AGMA Class 12, maintaining low vibration amplitudes above 10,000 RPM.

Technical Documentation & Compliance
  • Standard compliance - Factory-tested to latest API 610 (OH6 layout) with full pressure and flow hydraulic performance testing
  • Interchangeability guarantee - All core components (impeller, high-speed shaft, seals, casing) are 100% physically interchangeable with original LMV 311 pumps
Performance Advantages
LMV 311 High Speed Centrifugal Pump LMV 311 High Speed Centrifugal Pump LMV 311 High Speed Centrifugal Pump
Packing and Shipping
Product Packaging Shipping Details
One LMV311 High-Speed Vertical Centrifugal Pump Ships within 6 months
User manual and installation instructions Shipping weight: 75kgs
Safety instructions and warnings Shipping dimensions: 120*80*100cm (depending on pump)
Shipping carrier: UPS, FedEx, or Cargo
Shipping options: Standard or expedited
Technical FAQ
Can Sunstrand LMV 311 spare parts be used directly in my existing Sundyne pump?

Absolutely. Sunstrand's core components (impeller, shaft, seals, gears) are precision-manufactured to original equipment specifications, ensuring identical dimensional tolerances. Many customers are currently using Sunstrand spares to maintain their existing international-brand pump sets - a proven testament to our accuracy and reliability.

How does Sunstrand perform under low NPSH conditions?

For challenging suction pressure conditions, we offer a high-performance inducer option. This is based on hydraulic models refined from our database of 20,000 delivered units, reducing NPSHr by more than 50% and significantly improving cavitation resistance under extreme conditions.

How do you ensure that the alternative meets API 610 safety requirements?

Safety is Sunstrand's bottom line. Every LMV 311 undergoes a hydrostatic test at 1.5 times design pressure and full-power performance testing. We provide complete Material Test Reports (MTRs) and dynamic balance reports for each unit, ensuring compliance with - and often exceeding - petrochemical industry safety standards.
